BALLUFF BES 516-3022-E4-C-PU-05 Inductive standard sensors BES00L0
Dimension Ø 5 x 27 mm
Range 0.8 mm
Switching output PNP normally closed (NC)
Availability: 15 in stock
Manufacturer: BALLUFF
Type: Inductive standard sensors
Model: BES 516-3022-E4-C-PU-05
Part No: BES00L0
SAME Model: BES 516-3022-FO-X
Dimension Ø 5 x 27 mm
Style Housing M5x0.5
Installation for flush mounting
Range 0.8 mm
Switching output PNP normally closed (NC)
Switching frequency 5000 Hz
Housing material Stainless steel
Material sensing surface PBT
Connection Cable, 5.00 m, PUR
Operating voltage Ub 10…30 VDC
Ambient temperature -25…70 °C
IP rating IP67
| Manufacturer | BALLUFF |
|---|---|
| Model | BES 516-3022-E4-C-PU-05 Inductive standard sensors BES00L0 |
| Condition | New |
