BALLUFF BMF00A2 Magnetic field sensors for C-slot BMF 214K-PS-C-2A-SA2-S49-00,3

Manufacturer: BALLUFF
Type: Magnetic field sensors for C-slot
Model: BMF 214K-PS-C-2A-SA2-S49-00,3
Part No: BMF00A2

Dimension 16.8 x 2.9 x 4.5 mm
Principle of operation Magnetic field sensor
Connection M8x1-Male, 3-pin
Cable PUR, 0.3 m
Application Optimized response path especially suited for short-stroke cylinders.
Mounting part C-slot/SMC/ Bimba / Schunk
Housing material PA 12
Switching output PNP normally open (NO)
Switching frequency 7000 Hz
Operating voltage Ub 10…30 VDC
Ambient temperature -25…85 °C
IP rating IP67
