Manufacturer: BALLUFF
Type: Diffuse sensors
Model: BOS01CF
Series 18M
Dimension Ø 18 x 75 mm
Interface
PNP normally open (NO)
PNP normally closed (NC)
Principle of operation Photoelectric sensor
Principle of optical operation Diffuse sensor, energetic
Beam characteristic Divergent
Light type LED, red light
Light spot size Ø 50 mm at 600 mm
Range 0…600 mm
Connection Connector, M12x1-Male, 4-pin
Housing material Brass, nickel-plated
Material sensing surface Glass, anti-glare
Operating voltage Ub 10…30 VDC
