- SizeMidi
- SeriesD
- Actuator lockRotary knob with detent
- Mounting positionVertical +/- 5°
- Grade of filtration40 µm
- Condensate drainManually rotating
- Structural designShut off valve Filter regulator with pressure gauge
- Max. condensate volume43 ml
- Bowl guardMetal bowl guard
- Symbol00991523
- Pressure gaugewith pressure gauge
- Operating pressure1 bar … 16 bar
- Pressure regulation range0.5 bar … 12 bar
- Max. pressure hysteresis0.2 bar
- Standard nominal flow rate3150 l/min
- Operating mediumCompressed air as per ISO 8573-1:2010 [-:-:-] Inert gas
- Corrosion resistance class (CRC)2 – Moderate corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Air quality class at the outputCompressed air as per ISO 8573-1:2010 [7:8:4] Inert gas
- Temperature of medium-10 °C … 60 °C
- Ambient temperature-10 °C … 60 °C
- Product weight1600 g
- Type of mountingOptionally: Line installation With accessories
- Pneumatic connection 1G1/2
- Pneumatic connection 2G1/2
- Housing materialDie-cast zinc
- Material of bowlPC
