- Valve function3/2, closed, monostable
- Actuation typeElectrical
- Width30.5 mm
- Standard nominal flow rate800 l/min
- Pneumatic working portG1/4
- Operating voltageVia solenoid coil, to be ordered separately
- Operating pressure0.15 MPa … 0.8 MPa
- Operating pressure1.5 bar … 8 bar
- Structural designPlate seat
- Reset methodMechanical spring
- Certificationc UL us – Recognized (OL)
- Degree of protectionIP65
- Nominal width7 mm
- Width dimension32 mm
- Exhaust air functionWith flow control option
- Sealing principleSoft
- Mounting positionAny
- Manual overrideDetenting
- Type of controlPilot-controlled
- Flow directionNon-reversible
- Symbol00991041
- LapUnderlap
- Switching time off29 ms
- On switching time10 ms
- Max. positive test pulse with 0 signal2200 µs
- Max. negative test pulse on 1 signal3700 µs
- Coil characteristicsSee solenoid coil, to be ordered separately
- Operating mediumCompressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot mediaOperation with oil lubrication possible (required for further use)
- Corrosion resistance class (CRC)1 – Low corrosion stress
- LABS (PWIS) conformityVDMA24364-B1/B2-L
- Storage temperature-20 °C … 60 °C
- Temperature of medium-10 °C … 60 °C
- Ambient temperature-5 °C … 40 °C
- Product weight320 g
- Electrical connectionVia F coil, to be ordered separately
- Type of mountingOptionally: On terminal strip With through-hole
- Pilot exhaust air port 82M5
- Pneumatic connection 1G1/4
- Pneumatic connection 2G¼
- Pneumatic connection 3G1/4
- Note on materialsRoHS-compliant
- Seals materialNBR
- Housing materialDie-cast aluminum
