GEMU 514 50D1737 51 2RS617 Angle seat globe valve, Pneumatically operated 2″ DN50

Manufacturer: GEMU
Type: Angle seat globe valve, Pneumatically operated
Model: 514 50D1737 51 2RS617
Part No: 2″ DN50

The GEMÜ 514 2/2-way angle seat globe valve has a low-maintenance aluminium piston actuator and is pneumatically operated. The valve spindle is sealed by a self-adjusting gland packing providing low-maintenance and reliable valve spindle sealing even after a long service life. A wiper ring fitted in front of the gland packing protects the seal against contamination and damage.

Type: 514: Angle seat globe valve, pneumatically operated, aluminium piston actuator
DN: 50: DN 50
Body configuration: D: 2/2-way body
Connection type: 17: Spigot EN 10357 series A (formerly DIN 11850 series 2) / DIN 11866 series A
Valve body material: 37: 1.4408, investment casting
Seat seal: 5: PTFE
Control function: 1: Normally closed (NC)
Actuator version: 2: Operator size 2
Regulating cone: RS617: 60 m³/h – mod.EQ
