Manufacturer: HOHNER
Type: INCREMENTAL ENCODER
Model: AWI58S-081R081-500
Shaft diameter: 8 mm
Shaft Design: stainless steel Solid
Voltage supply: 10 … 30 VDC
Output current: 30 mA
Output Circuit: Push-Pull (HTL)
Signal Output: A, B
Max speed: 6.000 U/min
Max. Pulse Frequency: 100 kHz
Output Connections: Valve Connector, Radial
Protection Class: IP 65
Temperature: -30 … 70 °C
| Manufacturer | HOHNER |
|---|---|
| Model | AWI58S-081R081-500 ENCODER |
| Condition | Used |
