IFM electronic OA0108 Diffuse reflection sensor OAT-FKOA

Manufacturer: IFM electronic
Type: Diffuse reflection sensor
Model: OAT-FKOA
Part No: OA0108

Type of light infrared light
Housing rectangular

Function principle Diffuse reflection sensor

Frequency AC [Hz] 47…63
Operating voltage [V] 20…250 AC/DC
Max. power consumption [VA] 2
Protection class II
Reverse polarity protection no
Type of light infrared light
Wave length [nm] 880

Electrical design relay
Output function light-on/dark-on mode; (programmable)
Contact rating 250 V AC / 3 A / 360 VA, 125 V DC / 3 A / 30 W

Range [mm] 5…1500; (white paper 200 x 200 mm)
Range adjustable yes
Max. light spot diameter [mm] 370
Light spot dimensions refer to at maximum range
