Manufacturer: Muller Coax
Type: Coaxial Valve & Solenoid
Model: 5-BCD 10 DRNC
ports threads : G 3/8
function : NC / NO
pressure range : 0-250 bar
KV value : 1,5 m³/h
media gaseous : liquid
flow direction : as marked
switching cycles : 130 1/min
switching time : opening 30-3000 ms
closing : 30-3000 ms
media temperature : 60 °C direct mounted pilot valve
ambient temperature : 50 °C direct mounted pilot valve
weight : 3,5 kg
nominal voltage : Un 24 V DC
Un 230 V 40-60 Hz AC
protection IP65 (P54) DIN 40 050
energized duty rating ED 100%
connection
| Manufacturer | Muller Coax |
|---|---|
| Model | 5-BCD 10 DRNC |
| Condition | New |
