SANDPIPER SB25.SGN4SS diaphragm pump 105011

SANDPIPER SB25.SGN4SS

• Flow rate: up to 27 gallons per minute (102 liters per minute)
• Maximum discharge pressure: 125 psi (8.6 bar)
• Maximum suction lift: 17 feet (5.2 meters)
• Inlet and outlet size: 1 inch (25.4 millimeters)
• Wetted materials: Stainless steel, PTFE (Teflon), Santoprene, and Hytrel
• Maximum solids handling size: 1/8 inch (3.2 millimeters)
• Air inlet size: 1/2 inch NPT (12.7 millimeters)
• Maximum air pressure: 100 psi (6.9 bar)
