Seli SLI-15-s CONDUCTIVITY MEASURING UNIT FOR THE FOOD + PHARMACEUTICAL INDUSTRY

Seli SLI-15-s CONDUCTIVITY MEASURING UNIT FOR THE FOOD + PHARMACEUTICAL INDUSTRY

Manufacturer: Seli
Type: CONDUCTIVITY MEASURING UNIT FOR THE FOOD + PHARMACEUTICAL INDUSTRY
Model: SLI-15-s

Inductive measuring system for conductivity recording in plant engineering and process measuring technology
new, very compact design
robust construction in hygienic design
measuring ranges freely configurable via graphic display or software
housing made of stainless steel 1.4305
graphic display screen for conductivity, temperature and control
extremely fast response times
temperature: t90< 9 sec.
conductivity: t90< 1 sec. (damping=1)
FDA, EHEDG conform

analogue output for conductivity and temperature in each case 4…20mA
14 basic measuring ranges
4 measuring ranges remotely reversible
intelligent temperature compensation
temperature application ranges:
substance (permanent): 0ºC to 100ºC
substance max. (1h): 0ºC to 150ºC
modular process connection technology
installation in pipelines starting from pipe nominal diameter DN 50
