SICK WL12L-2B530 SMALL PHOTOELECTRIC SENSORS 1018252

Manufacturer: SICK
Type: SMALL PHOTOELECTRIC SENSORS
Model: WL12L-2B530
Part No: 1018252

Features
Functional principle Photoelectric retro-reflective sensor
Functional principle detail Autocollimation
Sensing range max. 0 m … 18 m
Polarisation filters Yes
Emitted beam
Light source Laser
Type of light Visible red light
Light spot size (distance) Ø 0.8 mm (300 mm)
Key laser figures
Normative reference EN 60825-1:2014, IEC 60825-1:2007
Laser class 2
Key LED figures
Wave length 650 nm

Supply voltage UB 10 V DC … 30 V DC
Ripple < 5 Vpp
Current consumption 55 mA
Protection class III
Digital output Type PNP  NPN
